Fence Height Detail

March 18, 2014Page 251 section

A diagrammatic detail identifying specific areas of the fence with proposed height variances of 2.1m, 2.8m, and 3m.

1 CALL TO ORDER
Identifies 2.8m fence height areasIdentifies 3m fence height area around gravel parking area

T OF LOT 1, S 8 AND 27, T, PLAN 1688.

Fence Height Detail

Site plan diagram showing property lines, a gravel parking area, retaining walls, and specific fence height requirements marked with red callouts.
Site plan diagram showing property lines, a gravel parking area, retaining walls, and specific fence height requirements marked with red callouts.

General Information

  • Scale: metres (Scale bar 0 to 10)
  • Notes:
    • application only.
    • observations vation=10.99).
    • Plan 4131.
    • r, 2013.
  • Reference Number: 14

Specified Fence Heights

  • 2.8m fence height (marked at the bottom left property corner near measurements 25.0 T Fence and 23.4)
  • 2.1m fence height (marked along the property line boundary)
  • 2.8m fence height (marked at the corner of the gravel parking area near measurement 26.9 T Fence)
  • 3m fence height (marked at the corner of the gravel parking area along the retaining wall near measurement 27.5 T Fence)

Diagram Labels

  • Property line
  • Edge of pavement
  • Gravel parking area
  • Retaining wall

Numerical Data and Measurements

  • Boundary and Distance Measurements: 0.18, 23.0, 23.6, 23.8, 23.1, 15.38 (along retaining wall), 22.38, 23.7, 23.8, 23.9, 24.1, 24.8, 0.14, 25.4, 0.20, 0.62, 25.5, 25.6, 25.7, 25.9.
  • Internal Site Measurements: 4.83, 5.03, 1.2, 0.20, 27.5, 3.43, 3.45, 3.26, 25.5, 24.5.
  • Fence Top Elevation Markers (T Fence):
    • 25.0
    • 28.3
    • 26.9
    • 27.5
    • 27.5
  • Other text fragments: sets, BL, PLAN, PC.
