Schedule 1 – Fence/Retaining Wall Location

March 18, 2014Page 311 section

A color-coded map defining 'Area A' through 'Area D' for the purpose of variance recommendations.

1 CALL TO ORDER
Area A: 2.8m fenceArea B: fence around parking spaceArea C: encroaching worksArea D: 2m fence

Schedule 1: Fence/Retaining Wall Location

Site plan diagram showing property lines, edge of pavement, and color-coded areas for proposed fence and retaining wall work with various metric dimensions.
Site plan diagram showing property lines, edge of pavement, and color-coded areas for proposed fence and retaining wall work with various metric dimensions.

Legend

  • Area A (2.8m fence)
  • Area B (fence around parking space)
  • Area C (encroaching works)
  • Area D (2m fence)

Map Details

  • Property line
  • Retaining wall
  • Gravel parking area
  • Edge of pavement
  • P24

Dimensions and Notations:

  • Area A: Total length of 22.38; portion along retaining wall is 15.38. Offset of 0.18 at the bottom left and 0.16 at the top junction.
  • Area B: Dimensions of 3.45 and 3.26 on the bottom edge; 5.03 and 4.83 along the right edge (retaining wall side).
  • Area C: Small hatched sections labeled with dimensions 0.20, 0.62 near the top left and 0.20, 1.2 near the top right.
  • Area D: Length of 4.83 with an offset of 0.14.
  • Other: Distance of 3.43 from the top of the works to the edge of pavement.
