Attachment 3 - Proposed Floor Plans and Site Plan

MAIN FLOOR PLAN (9'-0 3/4" WALLS)

Architectural floor plan for the main level of a residence, including room layouts for a kitchen, dining room, great room, laundry, powder room, and a two-car garage, with detailed dimensions and structural notes.

Room Dimensions

Dining: 13'1" x 7'1"
Great Room: 16' x 14'1"
Kitchen: 11'4" x 11'
Powder Room: 7'2" x 3'6"
Laundry: 6' x 8'2"
2 Car Garage: 21'1" x 19'7"
Covered Entry: 8'x6'

Area and Scale Information

Scale: 1/4" = 1' - 0"
Date: FEB 27 2014
Main Floor Area: 823 Sq Ft (76.5 Sq M)
Garage Area: 449 Sq Ft (41.7 Sq M)

Design Criteria (Part 9)

Item	Value
Roof	25
Floor	40
Assumed Soil Bearing Capacity	(Not specified)
Framing	All framing as per Part 9 BCBC
Lintels	All lintels are 2-2x10 U.P.

SITE PLAN - LOT 13

Site plan showing the footprint of the proposed single-family dwelling on Lot 13, including the driveway, property boundaries, and proximity to Jorgensen Court, a lane, and a park.

Lot Specifications

Lot 13 Area: 378.4 m²

Proposed Single Family Dwelling G.F.A.: 1,699 Sq Ft

Garage Area: 449 Sq Ft

Driveway: 6% Slope over 3.5m

Fronting Street: Jorgensen Court

Rear Access: Lane (28.270)

Adjacent Area: Park

Elevation Data

MFE: 71.4m

GFE: 71.2m

Fin Grade: 71.2

Avg Fin Grade: 71.2
