Council Meeting/Documents/Tower Profile (Rogers Tower)
Appendix

Tower Profile (Rogers Tower)

May 3, 2022Page 2361 section

Technical drawing showing the elevation and structural profile of the proposed 30m high monopole tower and lightning rod.

2 APPROVAL OF AGENDA
Max Elevation: ±33.0mEquipment: 6' x 8' equipment shelter and 5.1m x 7m wood fence

Site Plan

Detailed site plan showing a central building, surrounding landscaping, and property boundaries. The plan includes labels for "EXISTING Property line", "Road dedication Area", "NEW Property line", and identifies the adjacent "Galloping Goose Trail". A section is marked "Plan VIP61887 area = 342 m2".
Detailed site plan showing a central building, surrounding landscaping, and property boundaries. The plan includes labels for "EXISTING Property line", "Road dedication Area", "NEW Property line", and identifies the adjacent "Galloping Goose Trail". A section is marked "Plan VIP61887 area = 342 m2".
Page 236
