Council Meeting/Documents/Attachment 8 - Building Elevations
Appendix

Attachment 8 - Building Elevations

May 3, 2022Page 2391 section

Architectural drawings showing the exterior front and side elevations of the proposed building.

1 CALL TO ORDER
Architect: Parsi Development Ltd.Materials include concrete siding and prefinished metal.

Elevations - 8 & 10 Erskine Lane

Architectural drawings showing the front and side elevations of a multi-story residential building, including a materials schedule and project title block.
Architectural drawings showing the front and side elevations of a multi-story residential building, including a materials schedule and project title block.

Materials Schedule

  1. CONCRETE SIDING- WHITE
  2. PREFINISHED METAL SIDING- BLACK
  3. ALUMINUM WINDOWS- WHITE
  4. PREFINISHED ALUMINUM & GLASS GUARDS, ENGINEERED
  5. PREFINISHED TEMPERED GLASS PATIO DOOR
  6. CONCRETE SIDING- WOOD LOOK
  7. PREFINISHED METAL FASCIA- DARK GREY
  8. COMPOSITE METAL SIDING- LIGHT GRAY
  9. PREFINISHED ALUMINUM GUARDS, ENGINEERED
  10. ENTRY GLAZED DOOR
  11. CONCRETE

Elevation Views

  1. Front Elevation (Scale: 1/8" = 1'-0")
  2. Side Elevation (Scale: 1/8" = 1'-0")

Project Information

  • Project Name: 8 & 10 ERSKINE Lane
  • Address: 8 & 10 ERSKINE Lane, View Royal, BC
  • Developer: Parsi Development ltd.
  • Drawing Title: Elevations
  • Drawing Number: A301
Page 239
