Attachment 8 - Typical Floor Plan (Upper Levels)

May 3, 2022Page 2431 section

Architectural floor plan showing the layout of the residential units.

1 CALL TO ORDER
Shows unit Types A through G.

Floor Plan

Detailed architectural floor plan for a multi-unit residential building, showing unit types, square footages, common areas, and dimensions.
Detailed architectural floor plan for a multi-unit residential building, showing unit types, square footages, common areas, and dimensions.

Unit Type Summary

  • TYPE 'A': 605.00 S.F.
  • TYPE 'B': 713.00 S.F.
  • TYPE 'C': 870.00 S.F. (two units shown)
  • TYPE 'D': 995.00 S.F.
  • TYPE 'E': 880.00 S.F. (two units shown)
  • TYPE 'F': 660.00 S.F.
  • TYPE 'G': 945.00 S.F.
  • TYPE 'I': 650.00 S.F.

Additional Features

  • Lobby: Central access area at elevation 12.60.
  • ELEC. CLOSET: Located adjacent to the central stairwell and lobby.
  • Stairwells and Elevators: Centrally located for building access.
  • Exits: Clearly marked egress points.
