Roof Framing Plan - Attachment 2 (continued)

November 19, 2024Pages 104–1052 sections

Technical drawings and associated correspondence for the roof framing.

1 CALL TO ORDER- Councillor Brown, Acting Mayor called the meeting to order at 7:00 p.m.
Structural engineer: Mark Buesink, P.Eng.

Mark Buesink, P.Eng, P.E.

structural engineer

Detailed roof framing plan at 1/4" = 1'-0" scale. The drawing shows structural layout with beam labels (B3, B6, B7, B9), joists (J2, J3), and dimensions. A red-lined detail at the bottom illustrates a "continuous beam (min. 3-ply)" with support points and fastener specifications including "(5) GRK's @ 12" o/c" and "(3) GRK's @ 12" o/c".
Detailed roof framing plan at 1/4" = 1'-0" scale. The drawing shows structural layout with beam labels (B3, B6, B7, B9), joists (J2, J3), and dimensions. A red-lined detail at the bottom illustrates a "continuous beam (min. 3-ply)" with support points and fastener specifications including "(5) GRK's @ 12" o/c" and "(3) GRK's @ 12" o/c".
Page 104–105

buepoint consulting ltd

please cc [redacted] for efficient service

On Sat, Dec 3, 2022 at 12:16 PM John Becker [redacted] wrote:

Ok bud, between yesterday and today all the nails in cross members are in, from outside. Strapping is in except for LVL, front door. The ridge roof at front door is supported by 3 2x12 and fur post. Also the 2x6 wall at front door supports ridge, incase that's important.
