Council Meeting/Documents/Attachment 2: Site Plan
Appendix

Attachment 2: Site Plan

October 3, 2023Pages 26–272 sections

Site layout documentation including a 2005 aerial photo and a hand-drawn diagram showing lot and garage dimensions.

1 CALL TO ORDER- Mayor Tobias called the meeting to order at 7:01p.m.
Lot size: 819.498 sq mHouse size: 77.853 sq mGarage size: 39.019 sq mHand-drawn diagram labeled 'The Garage' showing 9.144 metres length

Lot size - 819.498 sq m House size - 77.853 sq m Garage size - 39.019 sq m House + Garage - 116.872 sq m House + Garage = 14.26% of yard.

2005 PHOTO

Page 26–27

25 Chancellor Avenue

Garage Schematic

Dimensional diagram of "The Garage" at 25 Chancellor Avenue, including a compass rose. The drawing shows a rectangular structure with dimensions of 4.2672 metres by 9.144 metres and a total area of 39.019 sq m.
Dimensional diagram of "The Garage" at 25 Chancellor Avenue, including a compass rose. The drawing shows a rectangular structure with dimensions of 4.2672 metres by 9.144 metres and a total area of 39.019 sq m.

The Garage

  • Area: 39.019 sq m
  • Length: 9.144 METRES
  • Width: 4.2672 METRES
  • Door: 2.743 m
  • Height: 3.658 m Tall
  • Roof: Flat Roof

Lot Size

  • 809.371 SQUARE METRES
  • 819.498 SQUARE METRES
Page 26–27
