Attachment 3: Building Concept

October 3, 2023Pages 28–291 section

Detailed hand-drawn architectural concept and materials list for the proposed accessory building.

1 CALL TO ORDER- Mayor Tobias called the meeting to order at 7:01p.m.

Materials: 3/4" Tongue & Grove Plywood, 2x10 joists, 6x6 corner postsDimensions: 9.144m long, 3.66m high

25 CHANCELLOR AVE

June 28 '23

Hand-drawn isometric sketch of a garage showing dimensions of 9,144 m in length and 3,66 m in height, accompanied by a front elevation detail and a site plan.

High-contrast version of the isometric, elevation, and site plan sketches.

Garage Dimensions and Layout

Length: 9,144 m
Height: 3,66 m
Front Elevation Total Width: 4.26 m
Front Elevation Height (to roof peak): 3,166 m
Garage Door Width: 2.74 m
Garage Door Height: 2.44 m
Roof Overhang: 30 cm
Fascia/Edge Detail: 25.4 cm

Site Plan

Distance between House and Garage: 4 m

Structural cutaway drawing of the garage detailing framing members, siding, and roofing materials.

High-contrast version of the structural cutaway drawing.

Construction and Material Specifications

Roofing: 3/4" Toung & Grove Plywood coated with Vinal coating
Roof Rafters: 2" x 10" spaced every 16"
Exterior Siding: 1" x 8" wood siding (Match house)
Wall Studs: 2" x 6" x 10' every 10'
Bottom Plate/Studs: 10' 2" x 4"
Header: 6" x 6" Header
Corner Posts: 6" x 6" Corner Posts x 4
Trim: 1" x 10" (at roof line)

Page 28–29
