Council Meeting/Documents/Attachment 18: DP4.1 - North Building Rendering
Appendix

Attachment 18: DP4.1 - North Building Rendering

March 7, 2017Page 481 section

Artist's color rendering of the North Building as viewed from the park pathway.

1. CALL TO ORDER

Eagle Creek Village Phase 2 - North Bldg

North Building Rendering

Architectural rendering showing the exterior of the multi-story North Building at Eagle Creek Village Phase 2, featuring wood-look, grey, and white siding with glass balconies, viewed from a park pathway behind a black fence.
Architectural rendering showing the exterior of the multi-story North Building at Eagle Creek Village Phase 2, featuring wood-look, grey, and white siding with glass balconies, viewed from a park pathway behind a black fence.

NOT FOR CONSTRUCTION

View Information

1 VIEW FROM PARK PATHWAY SCALE: N.T.S. (Reference: 1 / DP4.2)

Project Information

Location: Town of View Royal, British Columbia Consultant: Omicron Architecture Engineering Ltd. Address: 10th Floor, Canadian Centre, 800-450 SW Marine Drive, Vancouver, BC V5X 0C3, CANADA Contact: Tel: 1-877-622-3300, Fax: 604-262-9750, www.omicroncanada.com Project Number: 11 14 032 Drawn: RI Checked: IM Sheet: DP4.1

Issue History

# Date Remarks
1 NOV. 16, 2016 ISSUED FOR DP
2 JAN. 25, 2017 COMMITTEE OF WHOLE REVISIONS

General Notes

OMICRON ARCHITECTURE ENGINEERING LTD.

This drawing is a copyrighted instrument of service and remains the property of the Architect. All information contained herein is for use only in connection with the specific purpose of the project and for no other. It is not for construction and is for concept only. Some other consultants' work may be used or represented herein without written permission. Omicron shall not be liable for the accuracy of consultants' work or any other information. This document shall not be reproduced without written permission.

All dimensions, elevations, levels, and clearances shall be verified on site. Discrepancies shall be reported to the Architect for clarification before any work commences or materials are ordered. All dimensions are to be taken from the drawings only. Scale is not to be used for the execution of the work. The Contractor shall ensure that all possible hazards on the job site are marked and protected with reference to the Work Safe and other applicable regulatory agencies.

Where a wall symbol occurs the base structure of a load bearing or fire-rated wall construction is as follows:

  • W - Wood-stud
  • S - Steel-stud
  • O - Block-out
  • ST - Sound Insulation
  • C - Concrete
  • M - Masonry
  • FR - Fire-Protection
  • S - Steel
Page 48
