Council Meeting/Documents/Attachment 6 - Material Board

Appendix

Attachment 6 - Material Board

November 2, 2021Page 1661 section

A visual guide and legend for the exterior materials to be used in the 298 Island Highway project.

1 CALL TO ORDER

Materials include fibre cement panels (various colors), metal sunshades, and wood canopy elementsCast-in-place concrete

Attachment 6

298 ISLAND HIGHWAY - MATERIAL BOARD

Architectural rendering of the building elevation showing various grey and wood-textured panels

Architectural rendering detail of the building's upper floors and balconies

Architectural rendering detail of the ground floor facade with "SIGNAGE" placeholder

Architectural rendering detail of apartment windows and facade cladding

Architectural rendering detail of the top roofline and corner design

Architectural rendering detail of the ground-level entryway and base materials

Architectural rendering detail of facade window patterns and glass railings

Architectural rendering detail of a top-floor balcony and corner window

Architectural rendering detail of street-level storefronts and cafe area

MATERIAL LEGEND

No.	MATERIAL LEGEND
1	FIBRE CEMENT PANEL SYSTEMS. COLOR: LIGHT GREY.
2	FIBRE CEMENT PANEL SYSTEMS. COLOR: DARK GREY.
3	FIBRE CEMENT PANEL SYSTEMS. COLOR: WHITE.
4	FIBRE CEMENT PANEL. COLOR: ASH. WOOD TEXTURE.
5	FIBRE CEMENT PANEL. COLOR: MAHOGANY. WOOD TEXTURE.
6	FIBRE CEMENT PANEL SYSTEMS. COLOR: LIGHT BEIGE.
7	FABRIC AWNING. COLOUR: RED.
9	STOREFRONT GLASS & ALUMINIUM. COLOR: ALUMINUM.
10	METAL & AND GLASS GUARD RAIL. COLOR: ALUMINUM.
11	ALUMINUM WINDOW. COLOR: ALUMINUM.
17	CAST-IN-PLACE CONCRETE.
19	METAL SUNSHADE. COLOR: ALUMINUM.
20	WOOD & AND GLASS CANOPY.
21	METAL & AND GLASS CANOPY.
22	METAL AND GLASS CURTAIN WALL COLOR: ALUMINUM.
23	METAL AND GLASS CURTAIN WALL COLOR: CHARCOAL.

Material Swatches

1	2	3	4	5	6	7	9	10
Light Grey swatch	Dark Grey swatch	White swatch	Ash Wood swatch	Mahogany swatch	Light Beige swatch	Red Awning photo	Storefront photo	Guard Rail photo

11	17	19	20	21	22	23
Window photo	Concrete photo	Sunshade photo	Wood Canopy photo	Metal Canopy photo	Aluminum Curtain Wall photo	Charcoal Curtain Wall photo

Detail rendering showing horizontal metal sunshades

Detail rendering of the top corner facade and balcony

Detail rendering of glass guard rails on balconies

Detail rendering of facade section with mahogany wood-texture panels

Detail rendering of the roof edge profile

Detail rendering of ground floor outdoor retail/seating space

Detail rendering of window patterns on the building elevation

Detail rendering of upper floor facade and balconies

Detail rendering of the street-level storefront and sidewalk area
