Eagle Nest Residences - Sub-Zone Diagram

April 14, 2020Page 2851 section

An architectural sub-zone diagram for the proposed Eagle Nest residential development at 3 Helmcken Road.

1 CALL TO ORDER
3 Helmcken Road, Victoria, BCBuilding 1: 6 storeysBuilding 2: 4 storeysBuilding 3: 5 storeysTarget FSR of 1.48 to 1.49

Eagle Nest Residences - 3 Helmcken Road

Sub-Zone Diagram

Detailed landscape site plan for Eagle Nest Residences showing building footprints, community green space, woonerf, and retained landscape features
Detailed landscape site plan for Eagle Nest Residences showing building footprints, community green space, woonerf, and retained landscape features

The site is divided into three distinct sub-zones as follows:

Sub-Zone Lot Area FSR Building Height
SUB-ZONE 1 5,788 1.49 BUILDING 1 6 storeys
SUB-ZONE 2 4,023 1.49 BUILDING 2 4 storeys (+ 1/2 storey at P1)
SUB-ZONE 3 3,950 1.48 BUILDING 3 5 storeys

Site Layout and Features:

  • Surrounding Roads: Helmcken Road and Burnside Road.
  • Landscape and Open Space:
    • Community Green (central area)
    • Woonerf
    • Feature Rain Garden
    • Retained Rock Outcrop
    • Retained Trees and Landscape (perimeter areas)
  • Infrastructure:
    • Bus Stop (located on Helmcken Road)
    • Parkade Entry points (indicated on the north and east sides)
  • Building Details:
    • Building 2 includes a 3-storey wing.
    • Building 3 includes two 4-storey wings.
  • Property Boundary Details: Property lines and setbacks are indicated in millimeters (e.g., 8000, 7500, 4000, 6723, 2812, 17872, 17719, 6168, 7453, 3300, 4829).

Project Information

  • Project Name: Eagle Nest Residences
  • Address: 3 Helmcken Road, Victoria, BC
  • Architect: dHKarchitects
  • Drawing Title: Sub-Zone Diagram
  • Drawing No: A101
  • Revision No: 2
  • Project Number: 1827
  • Date: 27 FEB 2020
  • Scale: 1:250
  • Drawn by: NLC
  • Checked by: RAW
  • Drawing File: 1827 A200 Floor Plan.vwx

Revision History:

Rev Date Description
1 17 SEP 2018 ISSUED FOR REZONING
2 22 JAN 2020 ISSUED FOR REZONING
2 27 FEB 2020 ISSUED FOR REZONING

Office Locations:

  • Victoria Office: 977 Fort Street, Victoria BC V8V 3K3 | T 1 • 250 • 658 • 3367
  • Nanaimo Office: 102 - 5190 Dublin Way, Nanaimo BC V9T 0H2 | T 1 • 250 • 585 • 5810

NOTE: All dimensions are shown in millimeters.
