Council Meeting/Documents/Attachment 4. Photo Rendering - Bosley's Storefront
Appendix

Attachment 4. Photo Rendering - Bosley's Storefront

April 19, 2016Page 161 section

Visual rendering of the proposed additional logo sign on the building facade.

Date: March 7 2016Total logo sign area: 0.999m2

Attachment 4. Photo Rendering

EAGLE CREEK VILLAGE, 19 Helmcken Rd., Unit 120, View Royal, BC V8Z 5G5

Sign Specifications - Illuminated channel w/ routed cabinet face

  • cabinet = 164.5 x 28"H, 3" deep painted semi-gloss black
  • bosley's = 69.75 x 22.25"H w/ 7328 acrylic face
  • faced with digital print, returns painted black
  • by pet valu = 29" x 3.5" routed in aluminum face
  • backed w/ 7328 acrylic, illuminated with LEDs
  • total logo for permits: 69.75 x 22.25"H (1.769x0.565 = 0.999m2)

Sign Specifications - Routed cabinet face backed with acrylic

  • cabinet = 164.5 x 28"H, 3" deep painted semi-gloss black
  • green lines - 43.25" length each
  • paw = 19.75x27"H
  • at routed face back w/ acrylic & faced with digital print on clear
  • total for permits: 110.5 x 27"H (2.80x0.585 = 1.36m2)
Close-up of technical sign specifications including dimensions and material details
Close-up of technical sign specifications including dimensions and material details

Project Information

  • Project Name: Bosley's
  • Location: Storefront - Eagle Creek Village View Royal
  • Date: March 7 2016
  • Designer: MR
Close-up of project information block including project title, date, and designer initials
Close-up of project information block including project title, date, and designer initials
Page 16
