Council Meeting/Documents/Proposed Foundation Position Survey Plans - Lots 10 & 20
Appendix

Proposed Foundation Position Survey Plans - Lots 10 & 20

July 5, 2016Pages 26–272 sections

Survey plans by Island Land Surveying Ltd showing proposed setbacks and building envelopes.

8.1.a) Development Variance Permit No. 2016/08 - 2427 Chilco Road
May 9, 2016Section 98, Esquimalt District

PROPOSED FOUNDATION POSITION UPON PROPOSED LOT 20, SECTION 98, ESQUIMALT DISTRICT, PROPOSED PLAN EPP

NOTE: Building position must be confirmed by approving authorities prior to construction. Existing or proposed Rights of Way, Easements or Covenants are not shown.

Site plan diagram showing the proposed foundation position for Lot 20, including setbacks from the road and adjacent lots 19 and 21
Site plan diagram showing the proposed foundation position for Lot 20, including setbacks from the road and adjacent lots 19 and 21
File: 97-LIMONA-P6-P7-MF3 Zoning: CD-19
Date: May 9, 2016 Minimum Set-backs
Island Land Surveying Ltd.
1-15 Cadillac Avenue
Victoria, B.C. V8Z 1T3
TEL 250.475.1515 fax 250.475.1516
www.islandsurveying.ca		 Front: 4.5m
Rear: 6.0m

Side: 1.2m
Side, Flanking: 4.0m
Project information block for Lot 20 survey, detailing file reference, date, zoning, and setback requirements
Project information block for Lot 20 survey, detailing file reference, date, zoning, and setback requirements
Page 26–27

PROPOSED FOUNDATION POSITION UPON PROPOSED LOT 10, SECTION 98, ESQUIMALT DISTRICT, PROPOSED PLAN EPP

NOTE: Building position must be confirmed by approving authorities prior to construction. Existing or proposed Rights of Way, Easements or Covenants are not shown.

Site plan diagram showing the proposed foundation position for Lot 10, showing proximity to the road, park areas, and lot 11, with an integrated survey information table
Site plan diagram showing the proposed foundation position for Lot 10, showing proximity to the road, park areas, and lot 11, with an integrated survey information table
File: 97-LIMONA-P6-P7-MF3 Zoning: CD-19
Date: May 9, 2016 Minimum Set-backs
Island Land Surveying Ltd.
1-15 Cadillac Avenue
Victoria, B.C. V8Z 1T3
TEL 250.475.1515 fax 250.475.1516
www.islandsurveying.ca		 Front: 4.5m
Rear: 6.0m

Side: 1.2m
Side, Flanking: 4.0m
Page 26–27
