Council Meeting/Documents/Illustration of Phase 5 lots and parking layout
Appendix

Illustration of Phase 5 lots and parking layout

July 5, 2016Page 352 sections

Detail drawing of parking and driveway dimensions for a sample lot on Chilco Road.

8.1.b) Development Variance Permit No. 2016/01 - Thetis Vale Phase 6 - Parking Space Length Variance
Lot 61Chilco Road

parcel is subject to charges: Covenant FB341886, FB406799 & FB406802 Statutory Building Scheme FB407448

Property survey map showing Lot 61 and surrounding lots 53, 54, 55, 60, and 62 adjacent to Chilco Road, with detailed dimensions and elevations.
Property survey map showing Lot 61 and surrounding lots 53, 54, 55, 60, and 62 adjacent to Chilco Road, with detailed dimensions and elevations.
Page 35

Property Survey Details

Lot 61

  • Area: 354.2 Sq.m.
  • MFE (Minimum Finished Elevation): 68.9
  • GFE (Ground Finished Elevation): 68.6
  • Boundary Dimensions: 30.093, 12.199, 13.36, 30.193, 1.36
  • Interior Dimensions/Offsets: 0.61, 4.52, 10.05, 5.24, 1.28
  • Elevations: F71.4, F68.6

Lot 62

  • Features: Overhang, Driveway
  • Dimensions and Setbacks: 1.28, 10.67, 4.53, 0.67, 3.67, 2.63, 3.15, 11.162, 4.59, 10.6, 5.15, 0.81
  • Elevation Notes: 0=0.803, F68.6

Road and Site Information

  • Street: CHILCO ROAD
  • Features: Gutter
  • Elevations: G68.8, G71.4
Page 35
