Council Meeting/Documents/Proposed Foundation Position Survey Plans - Lund Road Lots 3 & 15
Appendix

Proposed Foundation Position Survey Plans - Lund Road Lots 3 & 15

July 5, 2016Pages 38–392 sections

Detailed survey plans showing building footprints and driveway setbacks for Lund Road properties.

8.1.b) Development Variance Permit No. 2016/01 - Thetis Vale Phase 6 - Parking Space Length Variance
May 5, 2016Plan EPP55963

PROPOSED FOUNDATION POSITION UPON LOT 3, SECTION 98, ESQUIMALT DISTRICT, PLAN EPP55963.

SCALE=1:400. All distances are in metres.

The parcel is subject to charges: Covenant FB408215 & CA4921870 Statutory Right of Way CA4041989, CA4921897, CA4921900 Statutory Right of Way CA4921901 & CA4921903

Site plan showing proposed foundation position on Lot 3 (368.8 m²), including lot dimensions and setbacks relative to Lund Road and adjacent lots 2 and 4.
Site plan showing proposed foundation position on Lot 3 (368.8 m²), including lot dimensions and setbacks relative to Lund Road and adjacent lots 2 and 4.
Project information block for Lot 3 site plan.
Project information block for Lot 3 site plan.
File: 97-LIMONA-P6-PP Zoning: CD-19
Date: May 5, 2016 Minimum Set-backs
Island Land Surveying Ltd.
1-15 Cadillac Avenue
Victoria, B.C. V8Z 1T3
TEL 250.475.1515 fax 250.475.1516
www.islandsurveying.ca		 Front: 4.5m
Rear: 6.0m

Side: 1.2m
Side, Flanking: 4.0m
Page 38–39

PROPOSED FOUNDATION POSITION UPON LOT 15, SECTION 98, ESQUIMALT DISTRICT, PLAN EPP55963.

SCALE=1:400. All distances are in metres.

The parcel is subject to charges: Covenant FB408215 & CA4921870 Statutory Right of Way CA4041989, CA4921897, CA4921900 Statutory Right of Way CA4921901 & CA4921903

Site plan showing proposed foundation position on Lot 15 (370.7 m²), adjacent to Lund Road, a park area, and lots 14 and 16.
Site plan showing proposed foundation position on Lot 15 (370.7 m²), adjacent to Lund Road, a park area, and lots 14 and 16.
File: 97-LIMONA-P6-PP Zoning: CD-19
Date: May 5, 2016 Minimum Set-backs
Island Land Surveying Ltd.
1-15 Cadillac Avenue
Victoria, B.C. V8Z 1T3
TEL 250.475.1515 fax 250.475.1516
www.islandsurveying.ca		 Front: 4.5m
Rear: 6.0m

Side: 1.2m
Side, Flanking: 4.0m
Page 38–39
