Appendix
Lund Rd Phase 6 Affected Lots (variances requested)
July 5, 2016Page 401 section
Annotated map identifying the specific lots requesting parking variances.
Lots 3, 4, 10-15, 17, 18 identified with red dots
Lund Rd Phase 6 Affected Lots (variances requested)
The document identifies several lots within the Lund Road Phase 6 development that are affected by requested variances. The affected lots are marked on the survey plan with red indicators.
Affected Lots
- Lot 3 (356.8 m²)
- Lot 4 (403.7 m²)
- Lot 11
- Lot 12 (419.9 m²)
- Lot 13 (375.4 m²)
- Lot 14 (355.3 m²)
- Lot 15 (370.7 m²)
- Lot 18 (355.0 m²)
Survey Plan Information
- Primary Access: Lund Road
- Connecting Roads: Cheam Road, Chilco Road
- Legal References:
- Plan EPP38347
- Covenant FB408215
- SRW CA3878928, CA4041989 & CA4041990
- Adjacent Lands:
- Canada Highway (WP63535)
- A PLAN EPP55043
- 33 PLAN VIP768
- Designated Park Areas:
- Park: 0.112 ha
- Park: 712.1 m²
- Park: 625.8 m²
- Park: 705.2 m²
- Park: 642.7 m²
- Other Lots on Plan:
- Lot 1: 401.3 m²
- Lot 2: 371.3 m²
- Lot 5: 454.7 m²
- Lot 6: 490.1 m²
- Lot 7: 607.1 m²
- Lot 8: 505.2 m²
- Lot 9: 452.8 m²
- Lot 10: 473.9 m²
- Lot 16: 380.4 m²
- Lot 17: 359.0 m²
- Lot 19: 514.0 m²
Page 40
