Tentative Plan of Subdivision at #14 Jedburgh Road

July 5, 2016Page 471 section

Detailed subdivision plan showing lot sizes and strata access.

8.1.c) Development Variance Permit No. 2016/07 - 14 Jedburgh Road
J.E. Anderson and AssociatesFebruary 15, 2016Nine lots total

TENTATIVE PLAN OF SUBDIVISION

AT 814 JEDBURGH ROAD

Tentative plan of subdivision for 814 Jedburgh Road, showing proposed lot divisions FS A through FS D and S1 through S5, including road dedications and strata access.
Tentative plan of subdivision for 814 Jedburgh Road, showing proposed lot divisions FS A through FS D and S1 through S5, including road dedications and strata access.

Legal Description: LOT 17 + 18, SECTION 8, ESQUIMALT DISTRICT, PLAN 4178

Surveyors and Engineers: J.E. Anderson and Associates VICTORIA | NANAIMO

Project Information:

Field Detail
Client HENRY LOUIE
Date FEBRUARY 15, 2014
Scale 1 : 500
Project Surveyor B.R. CARRIER
Design By MRK
Our File 28438
Revision 1

Proposed Lot Areas:

  • FS A: 613 m²
  • FS B: 612 m²
  • FS C: 628 m²
  • FS D: 610 m²
  • S1: 623 m²
  • S2: 615 m²
  • S3: 676 m²
  • S4: 627 m²
  • S5: 703 m² (Note: EXISTING HOUSE TO BE REMOVED)

Access and Roadways:

  • JEDBURGH ROAD (with 4m DEDICATED AS ROAD)
  • ISLAND HIGHWAY
  • C.P. STRATA ACCESS

File Reference: V:\DNL_ACAD2000_SERVER\29438_SITE.DWG DBL

Page 47
