Sign Plan - Admirals Walk Shopping Centre

July 5, 2016Pages 76–794 sections

Consolidated plan showing proposed signage locations and styles for mall tenants.

8.1.d) Form and Character Development Permit No. 2016/04 - 1499 Admirals Road - Admirals Walk
Graphic FX Sign WorksIdentifies signage for Pharmasave, Dollar Store, etc.

Signage Location Map

Aerial map of a commercial plaza located at the intersection of Hammond Road and Ashcroft Road. Red numbered markers (1 through 40) are distributed across the site to indicate specific locations for building and storefront signage.
Aerial map of a commercial plaza located at the intersection of Hammond Road and Ashcroft Road. Red numbered markers (1 through 40) are distributed across the site to indicate specific locations for building and storefront signage.
Page 76–79

Storefront Elevations - Locations 1 to 18

Architectural elevations of the main building complex showing storefronts and signage for the following units: * **1:** PHARMASAVE * **3:** SELECT MORTGAGE * **4:** Your Pet Pals * **9:** Curves * **11:** AVALON * **12:** DOLLAR STORE * **13:** BC SPCA Thrift Store * **14, 15, 16, 17, 18:** Generic "SIGNAGE" placeholder locations
Architectural elevations of the main building complex showing storefronts and signage for the following units: * **1:** PHARMASAVE * **3:** SELECT MORTGAGE * **4:** Your Pet Pals * **9:** Curves * **11:** AVALON * **12:** DOLLAR STORE * **13:** BC SPCA Thrift Store * **14, 15, 16, 17, 18:** Generic "SIGNAGE" placeholder locations
Page 76–79

Storefront Elevations - Locations 20 to 25

Architectural elevations for a separate building structure featuring signage for two primary tenants: * **mokahouse COFFEE:** Locations 20, 22, and 24 * **SUBWAY:** Locations 21, 23, and 25
Architectural elevations for a separate building structure featuring signage for two primary tenants: * **mokahouse COFFEE:** Locations 20, 22, and 24 * **SUBWAY:** Locations 21, 23, and 25
Page 76–79

Storefront Elevations - Locations 26 to 40

Architectural elevations showing storefronts and signage for the following businesses and professional offices: * **26, 27, 28:** LIQUOR STORE * **30:** Second Slice PIZZA * **32:** ULTIMATE WATER * **33, 34:** DENTAL * **35:** OPTOMETRY CLINIC * **38:** WINE KITS * **39:** BEAUTY NAILS & SPA * **40:** LITTLE TOKYO
Architectural elevations showing storefronts and signage for the following businesses and professional offices: * **26, 27, 28:** LIQUOR STORE * **30:** Second Slice PIZZA * **32:** ULTIMATE WATER * **33, 34:** DENTAL * **35:** OPTOMETRY CLINIC * **38:** WINE KITS * **39:** BEAUTY NAILS & SPA * **40:** LITTLE TOKYO
Page 76–79
